Test current

AUTO、1A、3A、5A、10A

Measuring range

0.8mΩ-0.8Ω    (10A)

1mΩ-2Ω         (5A)

5mΩ-3Ω         (3A)

10mΩ-10Ω       (1A)

Min resolution

0.1μΩ

Accuracy

±(0.5%±2dgt)

Display

LCD

Resistance display effective digits are 4 digits

Data storage

1000 groups

Working environment

Ambient temperature: 0℃～40℃ Relative humidity: <90%RH, no condensation

Power supply

Built-in lithium battery   AC 220V±10V，50Hz±1 Hz

Fuse 2A

Max power consumption

100W

Dimensions

360*290*170 （mm）

Weight

Instrument：4.85Kg  Wire box:9.5Kg
