I. Purpose And Scope

    This instrument is designed and manufactured in accordance with Method B of the American Society for Testing and Materials (ASTM) D2272-2009 "Determination of Oxidation Stability of Lubricating Oils" standard and the "NBSHT 0193-2022 Rotary Oxygen Bomb Method" standard. It is suitable for measuring the oxidation stability of oil products specified in the standard at two temperatures of 150 ℃ or 140 ℃. This instrument can be used to determine the oxidation stability of new and in-use turbine oils with the same composition (base oil and additives). (In the case of inaccurate requirements for experimental data, it can also be used to evaluate the oxidation stability of new mineral insulating oils containing 2,6-di-tert-butyl-p-cresol as a rapid evaluation method.)

II. Main Technical Specification And Parameters

1. Power supply：AC(220±10%)V； 60Hz

2. Total power consumption: ≤1000W

3. Temperature control point of test bath: 140℃, 150℃

4. Temperature control accuracy: ±0.1℃

5. Pressure measurement range: (0～1.6) MPa

6. Pressure measurement accuracy: ± 0.5%

7. Working mode: metal bath

8. Rotating speed of slewing mechanism: (100±5)r/min

9. Inclined angle of oxygen bomb and water level: 30°

10. Applicable environment: temperature: 15 ℃～ 28 ℃, relative humidity: ≤ 85%

11. Overall dimension: 280mm×500mm×510mm（L×W×H）

12.  GW: about 30kg
