Smart calibration

The sensor probe can automatically calibrate the zero point to ensure the readiness for each measurement;

Quick and gas-saving

After turning on the machine and entering the measurement state, the dew point measurement time for each SF6 air barrier is about 5 minutes;

Safe and reliable

It adopts self-locking joints imported from Germany, which are safe, reliable and airtight;

Mass storage

Adopting a large-capacity data storage design, it can store up to 250 sets of test data;

High definition display

Color screen directly display dew point, moisture, temperature, humidity, time, date and dew point curve;

Moving measurement

Built-in large capacity rechargeable lithium battery, a full charge can work for 10 hours；

Accurate measurement

The temperature compensation function is added to ensure the accuracy of the measurement results under various temperature conditions.

Local calibration

This machine comes with calibration function, do not need to connect the computer to complete the data calibration.

Technical parameter

dew-point

Measuring range

－60℃～+ 20℃

measurement accuracy

±1℃

ambient temperature

－40℃～＋80℃

environment humidity

0～100％ RH

Display device

4.3-inch color touch screen

power supply

AC 220V；Built-in rechargeable battery: can be used for more than 10 hours on a single charge

weight

4.5Kg

size

300 mm×150 mm×300mm

Operating temperature

－30℃～＋60℃
