Intelligent calibration

Sensor probe can automatically calibrate the zero point to ensure the readiness of each measurement;

Quick and air-efficient

After turning on and entering the measurement state, the measurement time for each SF6 gas insulation dew point is about 5min;

Safe and reliable

Use Germany imported self-locking joint, safe and reliable, no air leakage;

Mass storage

With a large data storage design, up to 250 groups of test data can be stored;

High-definition display

The color screen directly displays dew point, moisture, temperature, humidity, time, date and dew point curve;

Moving measurement

Built-in large capacity rechargeable lithium battery, a full charge can work for 10 hours;

Electronic flow

Equipped with high-precision electronic flow, flow control is more accurate;

Accurate measurement

The temperature compensation function is added to ensure the accuracy of the measurement results under various temperature conditions;

Local calibration

This machine comes with calibration function, do not need to connect the computer to complete the data calibration.

Technical parameters

Dew point

Measurement range

－80℃～+ 20℃

Measurement accuracy

±0.5℃(-60℃～+20℃)/+2℃(－80℃～-60℃)

Ambient temperature

－40℃～＋80℃

Ambient humidity

0～100％ RH

Display device

4.3 inch color touch screen

Power supply

AC 220V；Built-in rechargeable battery: one charge can be used for more than 10 hours

Weight

4.5 kg

Size

300 mm×150 mm×300mm

Operating temperature

－30℃～＋60℃
