I.Purpose And Scope

The instrument is designed and made as per the National Standard of People’s Republic of China GB/T8929 “Test Methods for Water Content of Crude Petroleum”. It is suitable to determine water content of crude petroleum as per GB/T8929.

II. Main Technical Specification And Parameters

1. Power supply: AC 220 V±10%, 50 Hz;

2. Heater: By an electric heater. 500WX2, The heating power can be adjusted continuously.

3. Distillation flask: 1000 ml;

4. Water receiver: 5 ml, the smallest scale division is 0.05 ml.

5. Condenser: 400 mm±5 mm;

6. Ambient temperature: -10 ℃～+35 ℃;

7. Relative humidity: ≤85%;
